rate aggregated
学习监控系统和micrometer的时候，接触了rate aggregated概念。
对于某些系统的监控，数据聚合的速率比绝对值更有意义。这类监控系统的数学计算更少。引用micrometer官网的一张图：
(来源：https://micrometer.io/docs/concepts#_client_side)
为了支持对数据进行rate aggregate，micrometer对当前发布间隔，通过记录step value来累计数值。
Micrometer efficiently maintains rate data by means of a step value that accumulates data for the current publishing interval.
发布间隔分为current和previous。每次轮询返回previous的值。一旦当前发布间隔结束，把current的值更新到previous。
TimeWindowMax
最大值衰减，对最近接收的采样值给予更高的权重。 TimeWindowMax使用ringbuffer方式(一个AtomicLong数组)实现最大值衰减。
/**
* An implementation of a decaying maximum for a distribution based on a configurable ring buffer.
*
* @author Jon Schneider
*/
public class TimeWindowMax {
@SuppressWarnings("rawtypes")
private static final AtomicIntegerFieldUpdater<TimeWindowMax> rotatingUpdater =
AtomicIntegerFieldUpdater.newUpdater(TimeWindowMax.class, "rotating");
private final Clock clock;
// ringbuffer反转间隔
private final long durationBetweenRotatesMillis;
// 留意ringbuffer是一个AtomicLong数组
// 采用值是double，保存数值的long bit
private AtomicLong[] ringBuffer;
private int currentBucket;
private volatile long lastRotateTimestampMillis;
@SuppressWarnings({"unused", "FieldCanBeLocal"})
private volatile int rotating = 0; // 0 - not rotating, 1 - rotating
public TimeWindowMax(Clock clock, long rotateFrequencyMillis, int bufferLength) {
this.clock = clock;
this.durationBetweenRotatesMillis = rotateFrequencyMillis;
this.lastRotateTimestampMillis = clock.wallTime();
this.currentBucket = 0;
this.ringBuffer = new AtomicLong[bufferLength];
for (int i = 0; i < bufferLength; i++) {
this.ringBuffer[i] = new AtomicLong();
}
}
}
基础操作是rotate，负责按照设置的滑动时间窗口重置ringbuffer，维护当前使用的槽位。
private void rotate() {
long timeSinceLastRotateMillis = clock.wallTime() - lastRotateTimestampMillis;
// 到达滚动ringbuffer的时间点
if (timeSinceLastRotateMillis < durationBetweenRotatesMillis) {
// Need to wait more for next rotation.
return;
}
// cas 并发检查
if (!rotatingUpdater.compareAndSet(this, 0, 1)) {
// Being rotated by other thread already.
return;
}
try {
int iterations = 0;
synchronized (this) {
do {
// 重置槽位数值
ringBuffer[currentBucket].set(0);
if (++currentBucket >= ringBuffer.length) {
currentBucket = 0;
}
timeSinceLastRotateMillis -= durationBetweenRotatesMillis;
lastRotateTimestampMillis += durationBetweenRotatesMillis;
} while (timeSinceLastRotateMillis >= durationBetweenRotatesMillis && ++iterations < ringBuffer.length);
}
} finally {
rotating = 0;
}
}
因为滑动窗口，因此在记录采样器数值时，要尝试更新所有的ringbuffer槽位。
/**
* For use by distribution summary implementations.
*
* @param sample The value to record.
*/
public void record(double sample) {
rotate();
// 把底层的二进制位转换为long类型。
long sampleLong = Double.doubleToLongBits(sample);
for (AtomicLong max : ringBuffer) {
updateMax(max, sampleLong);
}
}
private void updateMax(AtomicLong max, long sample) {
for (; ; ) {
long curMax = max.get();
if (curMax >= sample || max.compareAndSet(curMax, sample))
break;
}
}
新技能get：
- JUC没有AtomicDouble，只有AtomicLong。为了使用CAS乐观方式高效更新计数器的值(double类型)，直接把sample底层的二进制位转换为long类型更新到ringbuffer槽位！
读取数值，直接把当前槽位的long bit转为double类型。
/**
* @return An unscaled max. For use by distribution summary implementations.
*/
public double poll() {
rotate();
synchronized (this) {
return Double.longBitsToDouble(ringBuffer[currentBucket].get());
}
}
DistributionStatisticConfig
DistributionStatisticConfig是Timer和DistributionSummary的配置类。
sla
histogram会划分多个bucket。 sla用于指定发布哪些bucket。
expiry 和 bufferLength
/**
* Statistics like max, percentiles, and histogram counts decay over time to give greater weight to recent
* samples (exception: histogram counts are cumulative for those systems that expect cumulative
* histogram buckets). Samples are accumulated to such statistics in ring buffers which rotate after
* {@link #expiry}, with this buffer length.
*/
max, percentiles, and histogram 给最近的采样值更高的权重。采样值记录在ringbuffer环形数组。经过expiry时间之后，ringbuffer数组会被重置。
- bufferLength: ringbuffer数组长度。
- expiry: 采样值重置的时间间隔（The amount of time samples are accumulated to a histogram before it is reset and rotated.）。
percentiles
本地计算的百分比时序，因此不能跨dimension合并。
PrometheusTimer
有了上面的基础，来看看PrometheusTimer的相关实现。
public class PrometheusTimer extends AbstractTimer {
private static final CountAtBucket[] EMPTY_HISTOGRAM = new CountAtBucket[0];
private final LongAdder count = new LongAdder();
private final LongAdder totalTime = new LongAdder();
private final TimeWindowMax max;
@Nullable
private final Histogram histogram;
protected void recordNonNegative(long amount, TimeUnit unit) {
count.increment();
long nanoAmount = TimeUnit.NANOSECONDS.convert(amount, unit);
totalTime.add(nanoAmount);
max.record(nanoAmount, TimeUnit.NANOSECONDS);
if (histogram != null)
histogram.recordLong(TimeUnit.NANOSECONDS.convert(amount, unit));
}
}
使用LongAdder类型记录次数和总时间，这里考虑了相当高并发情况。 TimeWindowMax支持区间最值衰减。
PrometheusTimer另一个功能是返回累积直方图，这个放在以后再说。
